Technical Overview
Width of the appliance
598 mm
Height of the appliance
815 mm
Energy star rating
4.0
aqua stop
Yes
brilliantShine System
No
Gaggenau Home Connect
No
Specifications
6 programmes with aqua sensor and 2 options, Power and Intensive:
Clean and dry dishes in 80 minutes
Intensive cleaning in the lower basket while protecting glassware in the upper basket
TFT display for intuitive handling of all functions
Bright interior lighting
Very quiet: 40 dB
Aqua stop
Energy rating: 4 stars
TFT display indicating remaining or end time, refill for salt and rinsing agent, inflow of water.
Touch key operation.
Information key with use indications.
Time delay up to 24 hours.
Visual and acoustic end of program indicator.
Info-Light.
Bright interior lighting.
Glass protection.
Aqua sensor.
Load sensor.
Automatic detergent function.
hydryoDry heat exchanger assists with condensation to help dry dishes
Continuous flow heater.
Triple filter system.
Soft lock.
Aqua stop.
6 programs:
Auto 35 °C - 45 °C.
Auto 45 °C - 65 °C.
Auto 65 °C - 75 °C.
Standard Eco 45°C.
Quick wash 45 °C (29 min.).
Pre-rinse.
2 options:
Intensive.
Power.
Flexible basket system.
Cutlery drawer.
Upper basket:
Rackmatic with 3 levels, adjustable in height up to 5 cm.
2 folding spines.
2 folding racks.
Lower basket:
4 folding spines.
2 folding racks.
Maximum dish sizes (upper/lower basket)
27/25, 24.5/27.5 or 22/31 cm respectively.
15 place setting capacity.
4 star energy rating, 5 star WELS water rating
12 L water consumption per wash.
From 0.64 kWh.
Noise level 40 dB (re 1 pW).
Height-adjustable feet.
Appliance plinth recess 100 mm (see drawing).
Rear feet adjustable at front.
Door weight up to 8.5 kg.
Door panel dimension dependent on plinth height of kitchen furniture.
Connecting cable pluggable.
Water connection with 3/4" screw joint.
Connection to hot or cold water possible.
